BROADCAST SERIES
PATCH CORDS & MOLDED CABLE ASSEMBLIES
FAX: 773 792-2129
* Please visit the product pages on our website for the most up-to-date product information
3-CONDUCTOR TT PATCH CORDS:
ANALOG / AES/EBU AUDIO AND RS422 PATCHING
Switchcraft single 3-conductor TT audio patch cords have
now been designed with a low capacitance cable which at 110
Ohms is ideal for digital audio AES/EBU and SMPTE Mtime
code patching. The overall jacket is now flexible in eight colors.
The nickel plated plugs allow for non-tarnishing and the
overmolded handle-boot reduces strain off the cable when
pulled.
Switchcraft dual 3-conductor TT patch cords have also been
redesigned with an overall flexible cable and six colors to
choose from. Like the single TT the dual plugs are nickel
plated and flexible. These cords work with all Switchcraft
TT stereo spaced bays for analog audio and RS422 data
patching.
SPECIFICATIONS
Standard plug terminations are single 3-conductor TT.
Plug handle is molded thermoplastic.
Plugs: Tip Rod, Ring and Sleeve - Copper Alloy
Cable: 26 AWG (30x40) OFBC, 110 Ohm Low
Capacitance. Jacket is Matte PVC
Dual Bantam TT
TTD
267
TT
TTD
Tiny
Telephone
Length
(Feet)
Cable
Color
Tiny
Telephone
Length
(Feet)
Cable
Color
Dual
Part Numbering System
Video Patch Cords
Single Bantam TT
Dual Bantam TT
Video Patch
TT
TTD
Length (Feet) Cable Color
TTD Not available in purple or gray.
Colors
Color Code
Stock Lengths
1'
Black
Red
Orange
Yellow
Green
Blue
Purple
=
=
=
=
=
=
=
BK
R
O
Y
GN
BL
P
2'
3'
4'
5'
6'
7'
8'
Gray
=
GY
9'
10'
Single Bantam TT
TT
(Custom lengths are available by request)
1 Foot (12" inches) equals 3.28 meters
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
